Imperial |
Metric |
| Safe Working Load |
440 lbs. |
200 kg |
| Maximum Overall Length |
43.3 inches |
1100 mm |
| Minimum Overall Length |
41.0 inches |
1040 mm |
| Maximum Overall Height |
65.5 inches |
1665 mm |
| Minimum Overall Height |
48.4 inches |
1230 mm |
| Maximum Height to Attachment Point |
64.7 inches |
1644 mm |
| Minimum Height to Attachment Point |
39.2 inches |
995 mm |
| Turning Radius |
48.2 in. |
1225 mm |
| Legs Open - External Width |
39.1 in. |
995 mm |
| Legs Open - Internal Width |
34.3 in. |
870 mm |
| Legs Closed - External Width |
24.8 in. |
630 mm |
| Legs Closed - Internal Width |
20.0 in. |
510 mm |
| Widest Point (between support handles) |
29.0 in. |
738 mm |
| Overall Height of Legs |
4.7 in. |
120 mm |
| Ground Clearance |
1.4 in. |
35 mm |
| Front Twin Casters |
4.0 in. |
100 mm |
| Rear Braked Casters |
4 in. |
100 mm |
| Warranty |
2 Year |
|
| Weights |
|
|
| Mast, Base, Boom Assembly |
127.3 lbs. |
59 kg |
| Power Pack |
6.6 lbs. |
3.0 kg |
| Total |
|
62 kg |
| Base Assembly (not including battery) |
40.7 lbs. |
18.5 kg |
| Mast & Boom (not including battery) |
66 lbs. |
30 kg |
| Foot Tray |
23.1 lbs. |
10.5 kg |
