Imperial |
Metric |
| Safe Working Load |
341 lbs. |
155 kg |
| Maximum Overall Length |
39.4 in. |
1000 mm |
| Minimum Overall Length |
36.8 in. |
935 mm |
| Maximum Overall Height |
63 in. |
1600 mm |
| Minimum Overall Height |
44.5 in. |
1130 mm |
| Maximum Height to Attachment Point |
60.2 in. |
1529 mm |
| Minimum Height to Attachment Point |
28.4 in. |
721 mm |
| Turning Radius |
45.1 in. |
1145 mm |
| Legs Open - External Width |
38.2 in. |
970 mm |
| Legs Open - Internal Width |
34.5 in. |
876 mm |
| Legs Closed - External Width |
27.0 in. |
685 mm |
| Legs Closed - Internal Width |
22.2 in. |
564 mm |
| Widest Point (between support handles) |
18.8 in. |
478 mm |
| Overall Height of Legs |
4.3 in. |
109 mm |
| Ground Clearance |
1.2 in. |
30 mm |
| Front Twin Casters |
3 in. |
76 mm |
| Rear Braked Casters |
4 in. |
101 mm |
| Warranty |
2 Year |
|
| Weights |
|
|
| Mast, Base, Boom Assembly |
82.4 lbs. |
37.4 kg |
| Power Pack |
6.2 lbs. |
2.8 kg |
| Total |
88.6 lbs. |
40.2 kg |
| Base Assembly (not including battery) |
30.2 lbs. |
13.7 kg |
| Mast & Boom (not including battery) |
42.3 lbs. |
19.2 kg |
| Foot Tray |
9.9 lbs. |
4.5 kg |
